Maxima 3PH A3R ISO (15 To 80 Kva)

Protection against power cuts, high voltage, low voltage, damped oscillation, spikes and surges, harmonic distortion, clutter interference and frequency variation

The Maxima Series 3-Phase UPS is a high-efficiency, double-conversion online power protection system with an integrated isolating transformer. Designed for computers and communication devices, it offers reliable performance, reduced interference, and space-saving high power density.

Application:

Telecommunication
Finance
Transportation
Government
Manufacturing
Energy

Features:

Advanced DSP digital control technology effectively improving product performance and system reliability
Parallel redundancy
Provides superior protection especially in harsh industrial environments
High-definition HMI that ensures clear and easy operation.
User friendly interface
Plenty of accessories that meet a variety of needs

Description

The Sollatek Maxima Series 3-Phase UPS with isolating transformer, features high efficiency, high performance, double conversion, online mode, and three-in and three-out. With perfect power source protection solutions, the UPS effectively protects against multiple power source problems such as power cuts, high voltage, low voltage, damped oscillation, spikes and surges, harmonic distortion, clutter interference and frequency variation. Available from 15 to 80 kVA, it is the ideal solution for computers and communication devices. The internally integrated output transformers reduce equipment interference, and the higher power density of the entire unit saves you floor space.

Description (No Battery)	Product Code
Maxima 3PH ISO A3R 1.0pf NB 15K	9762T315-ISO
Maxima 3PH ISO A3R 1.0pf NB 20K	9762T302-ISO
Maxima 3PH ISO A3R 1.0pf NB 30K	9762T303-ISO
Maxima 3PH ISO A3R 1.0pf NB 40K	9762T304-ISO
Maxima 3PH ISO A3R 1.0pf NB 60K	9762T305-ISO
Maxima 3PH ISO A3R 1.0pf NB 80K	9762T306-ISO

Specification

Maxima Model	15 kVA	20 kVA	30 kVA	40 kVA	60 kVA	80 kVA
Capacity (VA/W)	15/13.5	20/18	30/27	40/36	60/54	80/72
Backup time
Unit Dimensions (WxDxH)	500x700x1200	500x700x1200	500x700x1200	500x700x1200	600x770x140	600x770x140
Unit Weight (W/O Battery) kg	230	230	255	290	400	550
